Nowadays, as the technology is rapidly improving day by day, in future, there may be no requirement of traditional methods to create Engineering Drawings and most of the companies also focusing on fast results through the usage of design software have to increase productivity to earn more and more profits. A student has to enhance his skills in Designing, Analysis and in executing a part program to reach for industry requirements. Keeping this in mind, the Department has provided a facility to the students to improve their professional skills by establishing CAD/CAM Laboratory in their curriculum. The CAD/CAM laboratory provides efficient skills on designing software and manufacturing a component.The students can draft a model in both 2D and 3D objects, can do analysis of the models, can write, can execute and can machine a component using CNC Machines Important things in the lab includes

1. CNC Milling Machine
2. CNC Lathe Machine
3. Computers for 2D and 3D modeling of mechanical components

Engineering Workshop has become important field in the industrial atmosphere to produce products for the service of mankind. The knowledge of converting a raw material into a useful product is highly essential for all engineers by familiarizing with concepts. The basic need of Engineering Workshop is to provide theoretical and practical knowledge of manufacturing environment to all the engineering students. Therefore, an attempt has been made through this laboratory to learn both the theoretical and practical knowledge of shaping a product. Considering the general needs of engineering students in the country and the fact that they hardly get any exposure to hand tools, equipments, machines and manufacturing setups, a basic course in Engineering Workshop remains a core subject for all the branches of engineering. This Engineering Workshop laboratory classes covers most of the basic skill that an engineering students needs to familiarize themselves.

The Engineering Workshop laboratory has four major sections such as Fitting shop, Carpentry shop, Sheet metal shop and Electrical wiring. The utility of each shop in shaping engineering students are discussed here as, Fitting Shop: The fitting shop is related to assembly of parts, after bringing the dimension or shape to the required size or form, in order to secure the necessary fit. Carpentry shop: Carpentry shop deals with making joints for a variety of applications like door frames, cabinet making furniture, packing etc. Sheet metal shop: In sheet metal shop an engineering student learns the art of making various house hold articles such as boxes, cans, funnels, ducts etc., which are made from a flat sheet of metals. Electrical wiring: Electrical wiring deals with understanding of various types of wiring systems, its associated devices and acquires skills in house wiring. Moreover it is essential for the practicing engineers to train the best practices and safety measures in electrical wiring.

LAB DESCRIPATION

The Fluid Mechanics & Hydraulic Machines laboratory is equipped with a number of equipment and experimental setups to study the fundamentals and applied aspects of fluid mechanics and hydraulic machines. Students can perform tests and find the flow rate of equipment like venturi meter and orifice meter. Bernoulli’s equation is verified through the Bernoulli’s apparatus. Frictional losses are determined by the apparatus named Losses in pipe friction. Measurements of critical Performance parameters like efficiency, flow rate etc. of various hydraulic machines such as turbines, pumps are performed in this lab.

The lab is also equipped with centrifugal and reciprocating pumps, Pelton Wheel, Francis and Kaplan Turbinesby which students can conduct the performance test todetermine the efficiency at different operating conditions.

List of equipment:

• Venturi Meter apparatus
• Orifice meter
• Bernoulli’s apparatus
• Losses in pipe friction apparatus
• Reciprocating Pump Test Rig
• Centrifugal Pump Test Rig
• Pelton Wheel Turbine Test Rig
• Francis Turbine Test Rig
• Kaplan Turbine Test Rig

Heat Transfer laboratory provides fundamental and industrial knowledge about modes of heat transfer, like conduction, convection and radiation, and their application. This lab is to provide the practical expose to the students with regard to the determination of amount of heat exchange in various modes of heat transfer.

This laboratory focuses on the study and calibration of different instruments used to measure the temperature, pressure, speed, and discharge of fluids.

• Material Science Laboratory aims in studying and understanding the microstructure of different metals – Copper & Aluminium, alloys - Stainless Steel, Case Carburized Steel & Bearing Metal, Cast Irons – Gray, Malleable & White Cast Irons, Low Carbon Steel & Medium Carbon Steel and Non – Ferrous Alloy – Brass, under a Metzer 57 Microscopes binocular microscope with proper polishing under ‘Double Disc Polishing Machines.
• Study of microstructure of heat treated steels can be done heating in ‘Muffle furnace with digital controller’.
• he Hardability of Steels can be calculated by using ‘Jominy End Quench Test Apparatus’.
• Grain Size, Phase, Decrabization, Coating Thickness, Nodularity, Particle Measurement, Density, Amalgamation can be measured for metals and alloys with the available Metzer-M Metallurgical Software (Microcam) by viewing and inspecting under ‘Metzer – M Co–Axial Trinocular Research Metallurgical Microscope Vision Plus – 5000 Tmm.

The Machine tool lab is equipped with state of the art machine tools such as Lathes, Milling Machine, Drilling Machine, Capstan Lathe, Shaper, Slotter, Cylindrical Surface Grinding machine and Tool & Cutter Grinder. By using these machine tools and machines can perform the metal removing operation on the rigid materials, usually by cutting operations like different types of Turning operations, Drilling, Milling, and Grinding, slotting and shaping irregular shapes.

Equipment List
• Lathe-No.10
• Milling machine
• Radial Drilling Machine
• Capstan Lathe
• Shaper
• Slotter
• Tool & Cutter Grinding Machine
• Cylindrical Surface Grinding Machine
• Lathe Tool Dynamometer

The main purpose of the lab is to understand the behaviour of the material under different load conditions and to determine the material properties like Tensile & compressive strengths, Young’s Modulus, rigidity Modulus, Impact Strength, Hardness, etc., by doing different experiments. In this laboratory, the equipment’s like universal testing machines, torsion equipment, spring testing machine, impact tester, hardness tester are used to determine the specified objectives.

Cycle-I

1. Compression strength test
2. Testing of permeability
3. Design and making of Single Piece Pattern
4. Design and making of Single Piece Pattern by using Wood Turn Lathe
5. Melting and Casting for Single Piece Pattern
6. Green Sand Molding for Double Piece Pattern

Cycle – II

1. ARC Welding
   • Effect of polarity
   • Effect of current
2. TIG Welding
3. Gas Welding
4. Spot Welding
5. Injection Molding
6. Hydraulic press

S No	Name of the equipment	Description	Image
1	Compression test	Testing the compressive strength of green sand by using compressive strength machine. The different combination of sand mixed with bentonite powder for conducting the experiments	Sand Rammer
2	permeability	Testing the permeability number of the sand by using the permeability experiment
3	Wood Turn Lathe	Wood turn lathe is used to prepare the pattern as per given dimensions with consideration of allowances. The prepared pattern is used in the mould preparation
4	Green Sand Mould	Green sand mould for single piece and double piece pattern is prepared for producing the replica of a designed pattern and mould cavity is filled with molten metal to produce the replica
5	ARC Welding	Arc welding equipment is used to produce the joints between the metals. We can able to conduct the experiments like direct current straight polarity, reverse polarity and effect of current on weld strength etc.
6	TIG Welding	TIG welding is used to join the metals which are having low melting point materials with less than 5 mm thick ness
7	Gas Welding	Oxy-acetylene welding uses a combination of oxygen and a fuel gas (typically acetylene) and is used primarily for welding thin metal sections. Oxy-gasoline welding utilizes a combination of oxygen and gasoline. This method can be more effective than acetylene for torch-cutting steel plates.
8	Spot Welding	Spot welding (also known as resistance spot welding) is a resistance welding process. This welding process is used primarily for welding two or more metal sheets together by applying pressure and heat from an electric current to the weld area. It works by contacting copper alloy electrodes to the sheet surfaces, whereby pressure and electric current are applied and heat is generated by the passage of current through resistive materials such as low carbon steels.
9	Injection Molding and Blow moulding	Injection molding is a process in which a thermoplastic polymer is heated above its melting point, resulting in the conversion of the solid polymer to a molten fluid with a reasonably low viscosity. This melt is mechanically forced, i.e.,injected, into a mold in the shape of the desired final object. Blow molding is the forming of a hollow object by inflating or blowing a thermoplastic molten tube called a “parison” in the shape of a mold cavity.
10	Hydraulic press	The equipment is used to produce the blanking and piercing operation And also it can be used to produce the required shape of the metal forming operations also can be performed by using hydraulic press

The Thermal Laboratory provides students with a lot of opportunities to study different types of IC engines, boiler models, and to do innovative projects. We can carry out the performance test, heat balance test, and retardation test on a variety of IC engines such as petrol/diesel fueled single/double cylinder engines with mechanical/electrical/hydraulic loading devices.

S.No.	Description	Instrument
1	Four Stroke Single Cylinder Water Cooled Diesel Engine Test Rig   This setup consists of an engine mounted on a sturdy base frame. The engine and the dynamometer are coupled using standard tyre coupling. Used for the performance test, Heat Balance sheet
2	Two Stroke Single Cylinder Air Cooled Petrol Engine Test Rig This engine setup is coupled with electrical loading device. Used for the Performance test, Heat Balance sheet. The experimental also includes the Motoring test to determining of friction power.
3	Four Stroke Multi Cylinder Water Cooled Petrol Engine Test Rig This engine setup is coupled with hydraulic loading device. Used for the Performance test, Heat Balance sheet. The experimental also includes the Morse test on multi cylinder engine and determining of friction power.
4	Boiler models There are 12 boiler Models available in the lab. The objective is to identify the type of boiler and working method

Overall View of thermal Engineering Laboratory
